Audi A4 (2001-2008) Pioneer DAB Digital Radio, 6.2″ Screen iPod iPhone Bluetooth Stereo Upgrade Pack

JVC KW-M560BT 6.8″ Digital Media Car Stereo

Package Includes

• JVC KW-M560BT 6.8″ Digital Media Receiver

• Double DIN Fascia Kit (Black)

• CAN-Bus Steering Wheel Control Adaptor (ISO & Quadlock Looms)

• Aerial Adaptor

• Audi Stereo Removal Keys

• Stereo Patch Lead

Vehicle Compatibility

Audi A4 (2001 – 2008)

• B6 / B7 (Typ 8E)

• Fascia Colour: Black

Fascia Adaptor

Converts the non-DIN factory aperture to a Double DIN size for aftermarket head unit installation. Designed to match the original interior colour, texture, and finish.

Aerial Adaptor

Required when replacing the factory-fitted stereo with an aftermarket head unit.

Steering Wheel Interface

Allows retention of factory steering wheel or stalk-mounted audio controls when installing an aftermarket stereo.

Stereo Removal Keys

Manufacturer-specific keys used to safely remove the original factory stereo without damaging the fascia or mounting cage.

General Features

• 2-DIN Digital Media AV Receiver

• 6.8″ capacitive touch monitor

• Apple CarPlay (wired via USB)

• Android Auto (wired via USB)

• Android USB mirroring (via Mirroring OA for JVC app)

• Built-in Bluetooth for hands-free calling and audio streaming

• Shallow chassis design for easier installation

• 13-band graphic equalizer

• Time alignment

• Rear view camera input

Display

• Screen Size: 6.8″ Wide VGA

• Touch Panel: Capacitive

• Customisable GUI

• Key Illumination: Blue

• Dimmer Function

• Multilingual Display

Smartphone Integration

• Apple CarPlay via USB

• Android Auto via USB

• Android screen mirroring via USB

• Android Bluetooth automatic pairing

Audio Features

• Maximum Power Output: 50W x 4

• Full Bandwidth Power: 22W x 4

• 13-band graphic EQ

• Preset EQ: 7 presets + 3 user

• Bass Boost

• High-pass / Low-pass filter

• Time alignment

• Subwoofer output with level and frequency control

Media Playback

• Audio: MP3, WMA, WAV, AAC, FLAC (USB)

• Video: H.264, WMV, MPEG 1/2, MPEG 4, AVI, MKV (USB)

Bluetooth

• Built-in Bluetooth (wired microphone included)

• Hands-free calling (HFP 1.6 Wideband Speech)

• Audio streaming and control (A2DP / AVRCP)

• Phonebook access and alphabetical search

• Auto pairing for iPhone and Android

USB

• Rear USB Port (High Speed)

• USB Power Supply: 1.5A charging

Radio Tuner

• FM / AM Tuner

• Radio Broadcast Data System (RBDS)

• Preset Stations: 20 (FM 15 / AM 5)

• Automatic preset memory

Inputs & Outputs

• AV Input: Mini-jack (AV-IN or Camera switchable)

• Video Output: RCA

• Rear View Camera Input

• Line Outputs: 2 Pre-outs + Subwoofer

• Pre-out Level: 2.0V

Installation & General

• Steering Wheel Control Ready (interface required)

• ISO Connector

• Wireless Remote Control Ready (RM-RK258 optional)

• Installation Size: 178 x 100 x 75 mm

• Weight: 1.3 kg

Important Notice

The JVC KW-M560BT has been discontinued. Orders will be supplied with the newer JVC KW-M593BT model.

Technical Specifications

• Screen: 6.8″ Touch Panel

• Size: Double DIN

• Max Power Output: MOS-FET 50W x 4

• Tuner: FM / AM

• Radio Data System: Yes

• Button Illumination: Blue

• Bluetooth: Built-in

• iPod Ready: Yes (USB or Bluetooth)

• Works with iPhone: Yes

• USB: Rear USB
