MATCH MEC ANALOG IN – MATCH DSP Extension Card With Analog In
Product parameters
- Application: For Amplifiers / DSP
- Type: Extension Card or Module
Description
Description
The MATCH Extension Card ANALOG IN extends MATCH products with two additional analog input channels. For example, the module allows to:
- provide MATCH DSP amplifiers with a low-level signal
- upgrade OEM premium sound systems which require additional high-level inputs
- connect additional analog signal sources such as a TV or smartphone
Of course, the high-level input provides our proprietary ADEP.3-circuit, the Auto Remote function as well as an adjustable input sensitivity from 1.5 to 30 Volts. Just as the high-level input the 3.5 mm low-level stereo input offers an adjustable input sensitivity. The adjustment range is from 0.5 to 8 Volts. The module will be delivered with a device-specific side panel.
- Extends the amplifier by two additional analog input channels
- High-level input with ADEP.3 circuit, Auto Remote switch and an adjustable input voltage from 1.5 to 30 Volts
- Low-level stereo line input via 3.5 mm jack with an adjustable input voltage range from 0.5 to 8 Volts
- Inputs can be freely configured via the DSP PC-Tool as additional Main Inputs or as an AUX source
- Device-specific side panel included in delivery
