6.8 inch WSVGA capacitive touch screen
White key illumination
Enhanced GUI and graphics
Enhanced smartphone connections:
Wired Apple CarPlay
Wired Android Auto
Wired iPhone and Android USB mirroring
Built-in Bluetooth technology
DAB+ digital radio tuner with FM (RDS) and AM support
High-speed USB input with up to 2.1A charging
Full HD video file format playback
Rear camera input
AV input
Video output
13-band graphic equaliser
Digital time alignment
Front, rear, and subwoofer pre-outs with 2.5V output
Steering wheel remote interface ready
Wireless remote ready
Single DIN short chassis design
Monitor Features
6.8-inch WVGA display (1024 × 600 px) with clear capacitive touch screen
Protective anti-fingerprint film
White key illumination
Fixed panel design
Three display modes: Full (initial), Auto (Full/Normal), Normal
Screen adjustments for brightness, tint, colour, contrast, and backlight
Dimmer sensor with manual, sync, and level control (Auto / On / Off)
NTSC / PAL auto detection
Display OFF mode
Graphical User Interface (GUI)
Demonstration mode (default ON)
Customisable home screen with four top source keys
Wallpaper customisation (six presets plus two user settings)
Text scroll support
Rear view camera interrupt with parking guidelines and on-screen caution
Visual source modes: Mirroring, CarPlay, Android Auto
Menu and text support for 14 languages
Tuner Features
FM and AM radio with 24 FM and 12 AM presets
RDS, EON, radio text plus, PTY, local seek, and traffic information
Manual and automatic memory entry
Auto1, Auto2, and manual tuning modes
Seek and scan up/down functions
DAB+ Tuner Features
DAB+ Band III tuner with 15 presets
Automatic DAB-DAB and DAB-FM switching
Seamless DAB-FM blending
Traffic information, PTY search, PTY watch, and ASW select
Alphabet and intelligent search
Dynamic label and slide show support
Audio formats: MPEG1 Audio Layer II, MPEG4 HE-AAC v2
Bluetooth Features
Wide-band hands-free calling support
Built-in high-quality microphone
Private mode and interrupt call request
Audio streaming with AAC and SBC codec support
Music library browsing with album artwork display
Phonebook access with alphabet search
Secure simple pairing and automatic pairing via USB
Optimised noise and echo cancellation
USB Input Features
High-speed USB Type-A port
Supports FAT16, FAT32, NTFS, and exFAT file systems
Up to 2.1A quick charging for supported devices
Mass storage class support
Tag information, album art, and time code display
List access, category search, and link search
Random and repeat playback options
Last position memory and resume playback
Supported Codecs (USB)
Audio: MP3, WMA, AAC, WAV, FLAC
Video: MPEG1, MPEG2, MPEG4, H.264, WMV, MKV
Images: JPEG, PNG, BMP
Android Features
Android Auto support via USB
USB mirroring for Android using compatible mirroring applications
Music playback via Bluetooth
Apple CarPlay and iPhone Features
Apple CarPlay support via USB
USB mirroring for iPhone using compatible mirroring applications
Audio Features
Maximum power output of 50W × 4
RMS power output of 22W × 4
Two RCA pre-outs (front and rear) plus mono subwoofer output
Balance and fader control
Volume offset for each source
Built-in amplifier off option
Digital Sound Processor (DSP)
Digital time alignment with position control and presets
13-band graphic equaliser with preset and user settings
High-pass and low-pass filters
Subwoofer phase and crossover control
Speaker size and channel level adjustment
Bass boost and loudness control
Video Features
AV output for supported USB sources
Rear camera input with NTSC and PAL auto switching
Connectivity
Wired steering remote interface ready
Learning steering remote support
Rear camera input
Video output
Rear USB 2.0 connection
Front, rear, and subwoofer pre-outs
FM/AM antenna input
DAB antenna input
General Features
Firmware and software update via USB
Backup memory support
Installation dimensions: 182 × 112 × 86 mm
Operating voltage: 14.4V (10.5–16V allowable)
Maximum current consumption: 15A
Weight: 1.3 kg
Accessories:
- 22Pin Molex Connector to ISO Connector lead
- GPS/Glonass antenna with mounting plate (3,5m cable)
- Extension Parking Cable (2m)
- 2DIN Sleeve & Lever
- 1DIN adapter bracket set (pre-mounted)
- Remover for Escutcheon (trim)
6.8” Wired Apple CarPlay, Android Auto, Apple/Android Mirroring, DAB+ radio Multimedia System
